model:

DWGS11TX

Power Supply:

AC220V/50/60HZsingle-phase

Function:

Single end peeling, single and double end ironing, single end crimping

Capacity:

2200 pieces / hour (length within 100-150 mm)

Machinable wire:

Fluorine resistant braided wire (compression wire)

Cut off length:

45mm --- 9999mm (special length can be customized)

Cut off accuracy:

Variation range: 1mm + cutting length * less than 0.2%

Peeling length:

2.0mm---15mm

Holding capacity:

2.0T (terminal machine)

Air pressure:

4-6kgf (clean and dry air required)

Detection device:

Check whether there is wire, check whether there is terminal pressing, check whether there is wire blocking, and check whether there is wire tying

Body size:

700W X 800L X 1500H(mm)

Body weight:

About 300kg
